| Pump Group | BST 68.16 6RZ | BST 68.20 6RZ |
|---|---|---|
| Standard | Optional | |
| Conc. Output (max) (Rod Side) | 160 m³/h (209,27 yd³/h) | 200 m³/h (261,58 yd³/h) |
| Conc. Pressure (max) (Rod Side) | 85 bar (1232,82 psi) | 85 bar (1232,82 psi) |
| Stroke | 26 Stroke/min | 27 Stroke/min |
| Concrete Cylinder Dimensions | 250 mm x 2100 mm (9,84″) x (82,68″) | 250 mm x 2500 mm (9,84″) x (98,48″) |
| Remote Control | HBC | HBC |
| Oil Cooler | Electric / Hydraulic | Hydraulic |
| Boom type | RZ |
| Sections | 6 |
| Boom swing time | 264 sec |
| Boom swinging angle | 360° |
| Delivery line | 125 mm (4,92″) (DN 125) |
| Vertical reach | 67.1 m (220’2″) |
| Horizontal reach | 63.1 m (207′) |
| Unfolding height | 12.7 m (41’8″) |
| Depth of reach | 41.8 m (171’7″) |
| End hose | 3 m (9’10”) 4″ Diameter |
